Mobile Floor Crane for Workshop Material Handling
Floor-based material positioning for workshops and warehouses.
| Capacity options | 200–1000 kg |
|---|---|
| Power options | 220 V or 380 V |
| Assembly | Motor, reducer, brake and rope drum |
Product role and applications
This floor-crane family combines a mobile support frame with electric lifting equipment. It suits material positioning where a compact crane must be brought to a working location. Frame mobility and powered lifting are different functions; the presence of wheels alone does not authorize travel with a suspended load.
Structure and compatibility
The documented lifting assembly includes a motor, reducer, brake and rope drum. These components work together to raise, hold and lower the hook. Supply voltage, hook travel, boom clearance and frame support must match the chosen configuration rather than being selected independently.
Features in practical use
The mobile base allows the equipment to be positioned near the task, while the powered drum provides hook movement. Match the quoted electrical supply to the available site supply and consider the cable route when planning the crane location and working clearance.
Specifications
| Capacity options | 200–1000 kg |
|---|---|
| Power options | 220 V or 380 V |
| Assembly | Motor, reducer, brake and rope drum |
| Reach | Project configuration |
Key features
- Mobile support frame
- Rotating boom with travel-limit protection
- Confirm hook height and travel clearance
Technical guide
Configuration explained
A load close to the frame and the same load farther away impose different demands. Check the chosen reach together with base geometry, load clearance and floor support. A listed 220 V or 380 V option also needs phase and frequency confirmation for the selected motor and controls.
- Supporting surface or structure
- Crane frame and mounting
- Boom reach and lifting path
- Load and attachment
Measure the floor-level travel route
This range lists capacity options from 200 to 1000 kg and 220 V or 380 V power configurations. Check doorway width, hook height, turning space and floor conditions before choosing the mobile frame.
Information to include in your inquiry
Record doorway width, turning space and the floor route between pickup and delivery. Supply the load weight, hook height and available voltage. The listed capacity and power options describe a range; the selected frame and reach require a specific configuration.
What changes the buying decision
A mobile floor crane must fit the route as well as the lifting point. Check doorways, floor condition, gradients and space for its support legs. Distinguish repositioning an unloaded crane from travelling with a suspended load; any loaded movement must be expressly permitted for the selected configuration.
Questions and answers
Can the machine move with a load?
Movement must follow the selected model’s instructions. Describe the intended travel operation so its suitability can be confirmed; wheels alone do not establish permission for loaded travel.
Are the 220 V and 380 V options otherwise identical?
The catalogue does not establish that. Confirm phase, frequency, motor and control configuration for the option being quoted.
Which load dimensions should accompany a floor-crane inquiry?
Give load weight, pickup position, attachment details and available clearance around the support legs, together with the required reach.
