ZLP630 Working Suspended Platform 630kg window cleaning gondola

وصف

Suspended Platform as a kind of Temporarily Installed Suspended Access Equipment, also known as Temporary Access Equipment, is a lightweight steel or aluminum-made object capable of carrying persons onto a certain height so as to facilitate the aerial work, such as maintenance, decoration, cleaning, etc.
It is easy for operation, flexible for moving, reliable in safety. Besides, it is not necessary to build scaffolding in the construction, the efficiency will be promoted and the cost will be reduced.Therefore, ACLASS ZLP series versatile knock-down platforms provides workers safer, easier and more efficient platform access.

Specifications

Model No.		ZLP630
Rated load(kg)		630
Lifting speed(m/min)		9～11
Hoister model		LTD63
Motor power(kw)		2×1.5
Brake torque(N.m)		15.2
Rated stretch of front beam(mm)		1100-1700
Suspending Platform	No. of platform rack	Single rack
	No. of platform	3
	L×W×H(mm)	(1.5+2+2.5)×690×1180
Suspending mechanism(kg)		2×175 Kg
Counterweight(kg) –optional		25×40pcs
Diameter of steel rope(mm)		8.3
Voltage(v) 3PHASES		220V/380V/415V (customized)
Ambient temperature		-20℃~+40℃
Ambient relative humidity		≤ 90%(25℃)

Applications:

1. Cleaning and maintaining of the exterior wall of high-rise building.
2. Painting, decoration and refurbishing of exterior walls.
3. Installation projects and other construction working of outer walls of high-rise building.
4. Aerial working of ship, large tower, bridge, dams and large chimneys.
5. Install and maintain for high-rise building elevator hoistway, shipbuilding industry, seagoing vessel, warships welding maintain.

Advantages:

. Professional quality: we have 7 years experience of exporting suspended working platforms in China.
2. Competitive price: we can do you a favor based on the factory status especially for big quantity.
3. Fast delivery: our monthly stock more than 1000 sets.
4. Considerate service: our excellent sales team keep the whole day email contact and 24 hours online. Engineers keep prompt reply for any questions.
5. We can customized the platform including parts according to your requirements.

The main Part:

1. Suspension Mechanism and Counterweight
The Height of the platform can be adjusted within 1150-1750mm with arm which can be stretched out and drawn back, it can be widely used parapet and complicated building in different height, and we can also supply customized platform to meet different requirement from the customers

2. Working Platform
Different material for different requests: Steel, Hot galvanized and Aluminum.
Various platform length for clients to choose.

3. Hoist Motor
LTD6.3 “a” shape hoist

4. Electrical Control box
Installed with international and national famous brands electrical components, our electrical control system consists of many protection devices, Such safety devices as electrical leakage protection device, automatic limited switch, overheat protection, emergency brake, current coverload proof, which make operate more easier, safer and reliable.

5. Safety Lock
When the steel wire rope is broken, blocked, slip out of he hoist or the working platform inclines, the safety lock will lock the rope within 100mm, this safety device is high advanced in China now.

Detailed Product Description

Condition: 100% New Suspended Platform
Load Capacity: 630kg
Standard Height: 100m
Rated Speed: 9-11m/min
Motor Power: 2*1.5kw
Material: Steel, Hot Galvanized Or Aluminum
Platform Length: 6m
Wire Rope Type: Working And Safety Type
